SOLA light engine®

Solid state white light excitation subsystems

Power and Control, 21st Century Illumination for 21st Century Microscopy

Lumencor’s SOLA light engines offer access to modern solid state illumination, with all its performance and efficiency benefits, at a price comparable to most metal halide light sources. With reliability and maintenance-free service built in, they provide sustainable and cost-effective replacements for traditional mercury-containing arc lamps. The SOLA SM model is designed to operate via simple manual on/off control or with the aid of a foot pedal. SOLA SE light engines provide all the features and benefits of SOLA SM models with added capabilities for electronic control of both light output on/off status and intensity. The new SOLA SE FISH light engines provide assay specific lighting for fluorescence in situ hybridization (FISH), with red shifted spectral outputs resulting in optimal matching to the excitation spectra of widely used nucleic acid hybridization probes.

SOLA Light Engines deliver more than enough output power for even the most demanding microscopy applications. Expect several watts of visible light output pumped through the liquid light guide coupling to your microscope. Integration of SOLA light engines with existing filter cubes and hardware configurations is straightforward. SOLA’s white light output falls almost entirely within the VISIBLE spectrum; no deeper UV or IR or extraneous heat is produced. With no bulb consumables to purchase and install, coupled to energy efficient operation, the initial investment in a SOLA Light Engine can be recouped in saved lamp operating costs savings within a few years.

Customers will never again have to worry about arc lamp alignment, installation and replacement. The expected lifetime of SOLA light engines is greater than 20,000 hours. Essentially no warm-up time and superior stability mean these are all usable hours with highly reproducible output power. This performance is backed by a 12- or 36-month warranty.

SOLA Light Engine Features

_Sources

Sources

Multiple solid state sources operating simultaneously to produce white light



_Power

Power

~ 3.5 W white light output though
3 mm dia liquid light guide (LLG)

Wavelength

Wavelength Range

380–680 nm (SOLA SM, SOLA SE, SOLA SE FISH)

350–680 nm (SOLA SM 365, SOLA SE 365, SOLA SE 365 FISH)



Warm-Up

Warmup Time

1 Second



_LightDelivery

Light Delivery

3 mm dia liquid light guide; LLG and microscope collimator sold separately



_EasyToInstall

Easy to Install

Pre-aligned, no maintenance

_Lifetime

Lifetime

> 20,000 hours



1_PowerRequirements

Power Requirements

120 W, 24 VDC, 5 A (SOLA SE and SOLA SM)

220 W, 24 VDC, 9.2 A (SOLA SE FISH)



_WeightDimensions

Weight

3.6 kg

Dimensions

12.5 cm x 26.3 cm x 16.3 cm

_Warranty

Warranty

SOLA SE models: 36 months SOLA SM models: 12 months



_ControlInterface

Control Interface

SOLA SE and SOLA SE FISH: USB connector for remote control by light engine control pod or host computer. BNC input port for TTL-activated electronic shutter. Manual on/off, foot pedal plug



_ControlInterface

Control Interface

SOLA SM: Manual on/off, foot pedal plug
